12V 200Ah LiFePO4 Deep Cycle Lithium Battery
ACOPOWER 12.8V 200Ah LiFePO4 Battery (200A BMS)
The ACOPOWER 12.8V 200Ah LiFePO4 battery delivers reliable power for off-grid solar systems, RV power storage, marine applications, and backup energy storage. With an advanced 200A BMS and over 4000 life cycles, this battery provides long-term performance and high safety.
Key Features
- High Capacity Energy Storage – 12.8V 200Ah battery providing up to 2560Wh energy.
- Built-in 200A BMS Protection – Protects against over-charge, over-discharge, and short circuit.
- Long Cycle Life – More than 4000 charge cycles for long-term solar energy storage.
- High Power Output – Supports up to 200A continuous discharge current.
- Lightweight LiFePO4 Technology – Safer and lighter compared with traditional lead-acid batteries.
Applications
- Solar energy storage systems
- RV & camper power systems
- Marine / boat electrical systems
- Off-grid cabins
- Backup power storage
Specifications
| Item | Specification |
|---|---|
| Battery Type | LiFePO4 |
| Nominal Voltage | 12.8V |
| Rated Capacity | 200Ah |
| Energy | 2560Wh |
| Cycle Life | ≥4000 cycles |
| Charge Voltage | 14.4V ±0.2V |
| Recommended Charge Current | 40A (0.2C) |
| Max Continuous Discharge | 200A |
| Max Output Power | 2560W |
Battery Dimensions
- Length: 21 in (532 mm)
- Width: 8.2 in (207 mm)
- Height: 8.5 in (215 mm)
Operating Temperature
- Charge: 0°C – 50°C (32°F – 122°F)
- Discharge: -20°C – 60°C (-4°F – 140°F)
- Storage: -10°C – 50°C (14°F – 122°F)
Expandable Battery System
The battery supports series and parallel connections for higher voltage or larger capacity systems. Up to 4 batteries can be connected in series (48V system) or multiple units in parallel for increased capacity.
Safety Protection
- Over-charge protection
- Over-discharge protection
- Short-circuit protection
- Over-current protection
- Temperature protection
User Manual
Original: $729.00
-70%$729.00
$218.70
Description
ACOPOWER 12.8V 200Ah LiFePO4 Battery (200A BMS)
The ACOPOWER 12.8V 200Ah LiFePO4 battery delivers reliable power for off-grid solar systems, RV power storage, marine applications, and backup energy storage. With an advanced 200A BMS and over 4000 life cycles, this battery provides long-term performance and high safety.
Key Features
- High Capacity Energy Storage – 12.8V 200Ah battery providing up to 2560Wh energy.
- Built-in 200A BMS Protection – Protects against over-charge, over-discharge, and short circuit.
- Long Cycle Life – More than 4000 charge cycles for long-term solar energy storage.
- High Power Output – Supports up to 200A continuous discharge current.
- Lightweight LiFePO4 Technology – Safer and lighter compared with traditional lead-acid batteries.
Applications
- Solar energy storage systems
- RV & camper power systems
- Marine / boat electrical systems
- Off-grid cabins
- Backup power storage
Specifications
| Item | Specification |
|---|---|
| Battery Type | LiFePO4 |
| Nominal Voltage | 12.8V |
| Rated Capacity | 200Ah |
| Energy | 2560Wh |
| Cycle Life | ≥4000 cycles |
| Charge Voltage | 14.4V ±0.2V |
| Recommended Charge Current | 40A (0.2C) |
| Max Continuous Discharge | 200A |
| Max Output Power | 2560W |
Battery Dimensions
- Length: 21 in (532 mm)
- Width: 8.2 in (207 mm)
- Height: 8.5 in (215 mm)
Operating Temperature
- Charge: 0°C – 50°C (32°F – 122°F)
- Discharge: -20°C – 60°C (-4°F – 140°F)
- Storage: -10°C – 50°C (14°F – 122°F)
Expandable Battery System
The battery supports series and parallel connections for higher voltage or larger capacity systems. Up to 4 batteries can be connected in series (48V system) or multiple units in parallel for increased capacity.
Safety Protection
- Over-charge protection
- Over-discharge protection
- Short-circuit protection
- Over-current protection
- Temperature protection
